Electrostatic Charging

For many years now Hildebrand Technology supplies successfully, as a competent and loyal partner, electrostatic charging equipment to many industries for all kind of different applications. Our system solutions are optimized for any material as well as for slow moving and high speed machines. All of our charging equipment can be used as an individual system or fully integrated in your process with an interface and function feedback. All charging systems are conform with the latest safety norms according EN and CE as well as ATEX standards.



Product Overview

"Electrostatic charging, charging  system, high voltage, iONtacker, Fusion, charging electrode"

iONtacker FUSION

Latest generation high efficiency static charging system. High voltage power unit integrated into charging electrode. Especially suitable for applications where high voltage cable can cause a problem and small dimensions are required.

  • Fully adjustable 0-20/30/40 KV - 30 Watt
  • Current- or voltage constant
  • Positive or negative output voltage
  • 5mm emitter pin pitch for highest charging field homogeneity
  • Emitter pin material made of Tungsten to achive longest possible pin life time
  • External control 0-10 V. Voltage and current monitor signal
  • Resistant against most common cleaning and solvent agents
  • Rigid POM electrode body, IP68

more info...

ContactRequest infoProduct info download
"iONtacker, Remote, charging system,  ions, high voltage power unit, electrostatic charges, Substrate surface"

iONtacker REMOTE

Fexible, cost effective charging system for a wide range of applications. Smallest possible electrode profile dimensions. Fits all Hildebrand charging electrodes. Especially suitable for applications where simple charging is required.

  • Fully adjustable 0-20/30/40 KV - 30 Watt
  • Current - or voltage constant
  • Positive or negative output voltage
  • 5mm emitter pin pitch for highest charging field homogeneity
  • Emitter pin material made of Tungsten to achive longest possible pin life time
  • Local or external control 0-10 V. Voltage and current monitor signal
  • Resistant against most common cleaning and solvent agents.
  • Rigid glas fibre enforced electrode body

more info...

ContactRequest infoProduct info download
"Electrostatic charging, charging  system, high voltage, iONtacker, Fusion, charging electrode"

iONtacker DUAL

Same spezification as iONtacker REMOTE. Especially suitable for applications where both polarities are needed at the same time.

  • Positive and negative output voltage integrated in same generator enclosure
ContactRequest info
"Electrostatic charging, charging  system, high voltage, iONtacker, Fusion, charging electrode"

iONtacker

Standard industrial charging system for a wide range of diffrent applications. Smallest possible electrode profile dimensions. Fits all Hildebrand charging electrodes. Especially suitable for applications where local display of output voltage and current is important.

  • Fully adjustable 0-20/30/40KV - 30/60Watt
  • Current - or voltage constant
  • Positive or negative output voltage
  • 5mm emitter pin pitch for highest charging field homogeneity
  • Emitter pin material made of Tungsten to achive longest possible pin life time
  • Local control, Voltage and current monitor display
  • Resistant against most common cleaning and solvent agents
  • Rigid glas fibre enforced electrode body
ContactRequest info
